LAN CABLE CAT6A
Type CAT6A CAT6A
CAT6A(uncontinual AL-foil)
Structure
Conductor Solid copper、Strand Bare copper、Strand tinned copper
Insulation PE、PP、FEP
Outer jacket PVC、LSZH、PE、TPU、PUR
Flammability CMX、CM、CMR、CMP、IEC60332-1、IEC60332-3C、CPR(Eca、Dca、Cca、B2ca)
Combination

PERFORMANCE CAT6A
Frequ-ency Attenu-ation NEXT PSNEXT Return Loss ELFEXT PSEL-FEXT
(MHz) (dB/100m) (dB/100m) (dB) (dB) (dB/100m) (dB/100m)
1 2.0 74.3 72.3 20 67.8 64.8
4 3.8 65.3 63.3 23 55.8 52.8
10 5.9 59.3 57.3 25 47.8 44.8
16 7.5 56.2 54.2 25 43.7 40.7
20 8.4 54.8 52.8 25 41.8 38.8
31.25 10.5 51.9 49.9 23.6 37.9 34.9
62.5 14.9 47.4 45.4 21.5 31.9 28.9
100 19.0 44.3 42.3 20.1 27.8 24.8
200 27.5 39.8 37.8 18 21.8 18.8
250 31.0 38.3 36.3 17.3 19.8 16.8
300 34.2 37.1 34.1 17.3 18.3 15.3
500 45.3 33.8 30.8 17.3 13.8 10.8
