LAN CABLE CAT6
Type CAT6 CAT6
no Cross
Structure
Conductor Solid copper、Strand Bare copper、Strand tinned copper
Insulation PE、PP、FEP
Outer jacket PVC、LSZH、PE、TPU、PUR
Flammability CMX、CM、CMR、CMP、IEC60332-1、IEC60332-3C、CPR(Eca、Dca、Cca、B2ca)
Combination

PERFORMANCE CAT6
Frequ-ency Attenu-ation NEXT PSNEXT Return loss ELFEXT PSEL-FEXT SRL. Delay
(MHz) (dB/100m) (dB/100m) (dB/100m) >=dB (dB/100m) (dB/100m) (dB/100m) (ns/
100m)
1 2.0 74.3 72.3 20 67.8 64.8 >23 542.0
4 3.8 65.3 63.3 23 55.8 52.8 541.5
10 6.0 59.3 57.3 25 47.8 44.8 541.2
16 7.6 56.2 54.2 25 43.7 40.7 541.2
20 8.5 54.8 52.8 25 41.8 38.8 23-10Lo
-g(f/20)		 541.2
31.25 10.7 51.9 49.9 24 37.9 34.9 541.4
62.5 15.4 47.4 45.4 22 31.9 28.9 541.8
100 19.8 44.3 42.3 20 27.8 24.8 542.0
200 29 39.8 37.8 18.0 21.8 18.8 542.5
250 32.8 38.3 36.3 17.3 19.8 16.8 542.7
